¡ô Ultrasonic transducer

Ultrasonic transducer for cleaner Ultrasonic transducer for welder and machine
¡ö Ultrasonic transducer for cleaner
Part No Static capacity
(pF)		 Resonance frequency
£¨kHz£©		 Resonance impedance
(¦¸) 		Max input power(W) Diameter of radiating surface(mm) Diameter of ceramic elements(mm) Connecting tap
RST-7950D-20H 5300 20 25 100 79 50 M10¡Á1
RST-6750D-25H 5300 25 25 120 67 50 M10¡Á1
RST-6945D-25H 4100 25 25 90 69 45 M10¡Á1
RST-5938D-25H 3800 25 25 60 59 38 M10¡Á1
RST-5938D-28H 3800 28 25 60 59 38 M10¡Á1
RST-4535D-28S 3000 28 25 50 45 35 M10¡Á1
RST-4935D-40H 3000 40 25 50 49 35 M10¡Á1
¡ö Ultrasonic transducer for welder and machine
Part No Static capacity
(pF)		 Resonance frequency
£¨kHz£©		 Resonance impedance
(¦¸) 		Max input power(W) Diameter of radiating surface(mm) Diameter of ceramic elements(mm)
RST-6160F-15S 8500 15 15 1600 61 60
RST-6160F-15SB* 17000 15 25 3200 127 60
RST-5150F-20S 11000 20 15 1000 51 50
RST-5150F-20SN 8700 20 15 1500 51 50
RST-5050D-20S 5300 20 20 600 50 50
RST-6950I-20R 16000 20 15 1500 69 50
RST-6950F-20R 11000 20 15 1000 69 50
RST-6350F-20R 11000 20 15 1000 63 50
RST-6345I-20R 16000 20 15 1500 63 45
RST-6345F-20R 9000 20 15 1000 63 45
RST-5638D-20R 3200 20 20 300 56 38
RST-5638F-20R 6500 20 15 600 56 38
RST-3325D-28S 2300 28 40 150 33 25
RST-3325F-28S 4500 28 30 300 33 25
* Double transducer
We can design and produce the specifications for transducers and it's boosters and ultrasonic horn according to the user's.
