◆ 大功率超声换能器
 |
 |
| 超声清洗换能器系列 |
塑料焊接及加工用换能器 |
■ 超声清洗换能器系列
| 型 号 |
电容(pF) |
谐振频率（kHz） |
谐振阻抗(Ω) |
功率容量(W) |
辐射面直径(mm) |
换能片直径(mm) |
连接螺孔 |
| RST-7950D-20H |
5300 |
20 |
25 |
100 |
79 |
50 |
M10×1 |
| RST-6750D-25H |
5300 |
25 |
25 |
120 |
67 |
50 |
M10×1 |
| RST-6945D-25H |
4100 |
25 |
25 |
90 |
69 |
45 |
M10×1 |
| RST-5938D-25H |
3800 |
25 |
25 |
60 |
59 |
38 |
M10×1 |
| RST-5938D-28H |
3800 |
28 |
25 |
60 |
59 |
38 |
M10×1 |
| RST-4535D-28S |
3000 |
28 |
25 |
50 |
45 |
35 |
M10×1 |
| RST-4935D-40H |
3000 |
40 |
25 |
50 |
49 |
35 |
M10×1 |
■ 塑料焊接及加工用换能器
| 型 号 |
电容(pF) |
谐振频率（kHz） |
谐振阻抗(Ω) |
功率容量(W) |
辐射面直径(mm) |
换能片直径(mm) |
备注 |
| RST-6160F-15S |
8500 |
15 |
15 |
1600 |
61 |
60 |
|
| RST-6160F-15SB* |
17000 |
15 |
25 |
3200 |
127 |
60 |
|
| RST-5150F-20S |
11000 |
20 |
15 |
1000 |
51 |
50 |
|
| RST-5150F-20SN |
8700 |
20 |
15 |
1500 |
51 |
50 |
|
| RST-5050D-20S |
5300 |
20 |
20 |
600 |
50 |
50 |
|
| RST-6950I-20R |
16000 |
20 |
15 |
1500 |
69 |
50 |
|
| RST-6950F-20R |
11000 |
20 |
15 |
1000 |
69 |
50 |
|
| RST-6350F-20R |
11000 |
20 |
15 |
1000 |
63 |
50 |
|
| RST-6345I-20R |
16000 |
20 |
15 |
1500 |
63 |
45 |
|
| RST-6345F-20R |
9000 |
20 |
15 |
1000 |
63 |
45 |
|
| RST-5638D-20R |
3200 |
20 |
20 |
300 |
56 |
38 |
|
| RST-5638F-20R |
6500 |
20 |
15 |
600 |
56 |
38 |
|
| RST-3325D-28S |
2300 |
28 |
40 |
150 |
33 |
25 |
|
| RST-3325F-28S |
4500 |
28 |
30 |
300 |
33 |
25 |
|
注：*双换能器
本公司可以根据客户的需要设计制造各种超声换能器、变幅杆和工具头。
|
|
|
 |
|
