RSP-82系列
| 型 号 |
电容量CT(pF) |
损 耗
tgδ(%) |
谐振频率
Fs(kHz) |
耦合系数
Kp(%) |
品质因数
Qm |
|
RSP-82-Φ10×Φ5×2
|
265 |
0.3 |
154.7 |
53.0 |
800 |
| RSP-82-Φ13×Φ5.3×2.2 |
455 |
0.3 |
126.8 |
53.0 |
800 |
| RSP-82-Φ15×Φ6×2 |
670 |
0.3 |
110.0 |
53.0 |
800 |
| RSP-82-Φ18×Φ8×7 |
265 |
0.3 |
89.0 |
53.0 |
800 |
| RSP-82-Φ20×Φ8×6 |
400 |
0.3 |
82.9 |
53.0 |
800 |
| RSP-82-Φ20×Φ10×5 |
425 |
0.3 |
77.3 |
53.0 |
800 |
| RSP-82-Φ25×Φ10×5 |
750 |
0.3 |
66.3 |
53.0 |
800 |
| RSP-82-Φ25×Φ12×5 |
690 |
0.3 |
62.7 |
53.0 |
800 |
| RSP-82-Φ30×Φ10×5 |
1140 |
0.3 |
58.0 |
53.0 |
800 |
| RSP-82-Φ30×Φ12×5 |
1075 |
0.3 |
55.0 |
53.0 |
800 |
| RSP-82-Φ32×Φ12×5 |
1255 |
0.3 |
52.7 |
53.0 |
800 |
| RSP-82-Φ35×Φ15×5 |
1425 |
0.3 |
46.4 |
53.0 |
800 |
| RSP-82-Φ38×Φ15×5 |
1735 |
0.3 |
43.8 |
53.0 |
800 |
| RSP-82-Φ40×Φ12×5 |
2075 |
0.3 |
44.6 |
53.0 |
800 |
| RSP-82-Φ40×Φ15×5 |
1960 |
0.3 |
42.2 |
53.0 |
800 |
| RSP-82-Φ45×Φ15×5 |
2565 |
0.3 |
38.7 |
53.0 |
800 |
| RSP-82-Φ45×Φ17×5 |
2475 |
0.3 |
37.4 |
53.0 |
800 |
| RSP-82-Φ49×Φ23×6 |
2225 |
0.3 |
32.2 |
53.0 |
800 |
| RSP-82-Φ50×Φ17×5 |
3150 |
0.3 |
34.6 |
53.0 |
800 |
| RSP-82-Φ50×Φ17×6.5 |
2425 |
0.3 |
34.6 |
53.0 |
800 |
| RSP-82-Φ50×Φ17×7.5 |
2100 |
0.3 |
34.6 |
53.0 |
800 |
| RSP-82-Φ50×Φ20×6 |
2495 |
0.3 |
33.1 |
53.0 |
800 |
| RSP-82-Φ50×Φ20×7 |
2135 |
0.3 |
33.1 |
53.0 |
800 |
| RSP-82-Φ50×Φ23×6 |
2340 |
0.3 |
31.8 |
53.0 |
800 |
| RSP-82-Φ50×Φ23×6.5 |
2170 |
0.3 |
31.8 |
53.0 |
800 |
| RSP-82-Φ50×Φ23×7 |
2005 |
0.3 |
31.8 |
53.0 |
800 |
| RSP-82-Φ55×Φ20×8 |
2340 |
0.3 |
30.9 |
53.0 |
800 |
| RSP-82-Φ55×Φ26×7 |
2390 |
0.3 |
28.6 |
53.0 |
800 |
| RSP-82-Φ60×Φ30×10 |
1925 |
0.3 |
25.8 |
53.0 |
800 |
| RSP-82-Φ69×Φ33×11 |
2380 |
0.3 |
22.7 |
53.0 |
800 |
| RSP-82-Φ70×Φ30×10 |
2850 |
0.3 |
22.7 |
53.0 |
800 |
| RSP-82-Φ100×1.4-200 |
52000 |
0.3 |
23.0 |
53.0 |
800 |
RSP-43系列
| 型 号 |
电容量CT(pF) |
损 耗
tgδ(%) |
谐振频率
Fs(kHz) |
耦合系数
Kp(%) |
品质因数
Qm |
| RSP-43-Φ10×Φ5×2 |
350 |
0.3 |
142.0 |
60.0 |
1000 |
| RSP-43-Φ13×Φ5.3×2.2 |
580 |
0.3 |
116.0 |
60.0 |
1000 |
| RSP-43-Φ15×Φ6×2 |
900 |
0.3 |
101.5 |
60.0 |
1000 |
| RSP-43-Φ15×Φ6×3 |
600 |
0.3 |
101.5 |
60.0 |
1000 |
| RSP-43-Φ15×Φ6×4 |
450 |
0.3 |
101.5 |
60.0 |
1000 |
| RSP-43-Φ25×Φ10×5 |
1000 |
0.3 |
60.9 |
60.0 |
1000 |
| RSP-43-Φ30×Φ15×5 |
1285 |
0.3 |
47.0 |
60.0 |
1000 |
| RSP-43-Φ35×Φ15×5 |
1905 |
0.3 |
42.6 |
60.0 |
1000 |
| RSP-43-Φ38×Φ12.7×6 |
2035 |
0.3 |
42.0 |
60.0 |
1000 |
| RSP-43-Φ38×Φ15×5 |
2320 |
0.3 |
40.2 |
60.0 |
1000 |
| RSP-43-Φ38×Φ15×6.5 |
1785 |
0.3 |
40.2 |
60.0 |
1000 |
| RSP-43-Φ40×Φ15×5 |
2620 |
0.3 |
38.7 |
60.0 |
1000 |
| RSP-43-Φ49×Φ23×6 |
2820 |
0.3 |
29.6 |
60.0 |
1000 |
| RSP-43-Φ50×Φ17×6.5 |
3240 |
0.3 |
31.8 |
60.0 |
1000 |
| RSP-43-Φ50×Φ17×7.5 |
2805 |
0.3 |
31.8 |
60.0 |
1000 |
| RSP-43-Φ50×Φ20×6 |
3330 |
0.3 |
30.5 |
60.0 |
1000 |
| RSP-43-Φ50×Φ20×7 |
2855 |
0.3 |
30.5 |
60.0 |
1000 |
| RSP-43-Φ50×Φ23×6.5 |
2890 |
0.3 |
29.2 |
60.0 |
1000 |
| RSP-43-Φ50×Φ23×7.5 |
2505 |
0.3 |
29.2 |
60.0 |
1000 |
| RSP-43-Φ60×Φ30×10 |
2570 |
0.3 |
22.7 |
60.0 |
1000 |
| RSP-43-Φ25×2-S |
2975 |
0.3 |
168.0 |
60.0 |
1000 |
| RSP-43-Φ25×2.2-S |
2700 |
0.3 |
168.0 |
60.0 |
1000 |
| RSP-43-Φ50×3.5-S |
5930 |
0.3 |
42.0 |
60.0 |
1000 |
| RSP-43-Φ50×5-S |
4150 |
0.3 |
42.0 |
60.0 |
1000 |
| RSP-43-90×14×8-∠5 |
1960 |
0.3 |
17.5 |
60.0 |
1000 |
| RSP-43-85×14×8.5-∠4 |
1710 |
0.3 |
18.6 |
60.0 |
1000 |
| RSP-43-80×14×9-∠3 |
1490 |
0.3 |
19.7 |
60.0 |
1000 |
| RSP-43-80×14×12-∠3 |
1110 |
0.3 |
19.7 |
60.0 |
1000 |
RSP-42系列
| 型 号 |
电容量CT(pF) |
损 耗
tgδ(%) |
谐振频率
Fs(kHz) |
耦合系数
Kp(%) |
品质因数
Qm |
| RSP-42-Φ45×Φ22×5 |
2480 |
0.3 |
17.2 |
55.0 |
700 |
| RSP-42-99×9×11.5 |
775 |
0.3 |
17.2 |
55.0 |
700 |
| RSP-42-99×8×12 |
660 |
0.3 |
17.2 |
55.0 |
700 |
| RSP-42-99×9×12.5 |
715 |
0.3 |
17.2 |
55.0 |
700 |
| RSP-42-90×14×8-∠5 |
1660 |
0.3 |
19.2 |
55.0 |
600 |
| RSP-42-85×14×8.5-∠4 |
1450 |
0.3 |
20.3 |
55.0 |
600 |
|
|
 |
|
